Coughed up for a Koffle

Anonymous · Post by **Anonymous** » Mon Mar 16, 09 10:38 am

marc-jerryatric wrote:Like i say Ad we had the issue as did Andy Frost, and i've just got back from pub with my mate who works at EDA and he says you should never bump the motor backwards, especially not with a Jesel belt drive,

Hey Marc , did you ask him why the motor should'nt be spun back & what problems they had?

Pete · Post by **Pete** » Mon Mar 16, 09 10:43 am

If its like a 'tina, the belt goes slack and it skips a tooth or two....the difference between "drive" and "driven" tension....only rotate the motor in one direction - if you go too far its only another 358ish degrees to wind the motor....

mopar_mark · Post by **mopar_mark** » Mon Mar 16, 09 6:58 pm

Pete wrote:If its like a 'tina, the belt goes slack and it skips a tooth or two....the difference between "drive" and "driven" tension....only rotate the motor in one direction - if you go too far its only another 358ish degrees to wind the motor....

There is no belt tensioner on BBM Jesel. The bottom tooth pulley fits onto the crank. The top pulley pulls up onto a taper, which is what fixes the centres & pre sets belt tension.

Pete · Post by **Pete** » Mon Mar 16, 09 8:38 pm

Learn something every day.

Why the difference between forward and backward cranking if the set-up is symmetrical??

Anonymous · Post by **Anonymous** » Mon Mar 16, 09 9:37 pm

Not saying some have'nt had issues with this , alli know is the cam degreed with no problems , the crank was turned back many times for the .050 figures , was checked , double checked & triple checked back & forth , was kind of hoping the above problem would rear it's head.

BTW , triple checkin was an understatement

, figures were consistant every time.

Will check again when finally degreed @ retainer.

Anonymous · Post by **Anonymous** » Mon Mar 16, 09 9:42 pm

Pete wrote: its only another 358ish.

Hey Pete , better double that figure.

Stu · Post by **Stu** » Tue Mar 17, 09 7:08 pm

Don't understand half of this, but it's very interesting reading!

mopar_mark · Post by **mopar_mark** » Wed Mar 25, 09 7:35 pm

As there were a few questions on a Jesel, thought I would post a couple of pictures, as I just fitted new Top & Bottom seals

Jesel - Without Pulleys & belt - shows the camshaft pulley taper which determines belt tension & centres

Jesel - With Pulleys & belt fitted

Have used a home made Harmonic balancer remover for years, got the job done, but was always a bit of a struggle.

Anyway, to cut a long story short, I bought one for $80. Boy if I had known how good they are. I would of bought one as soon as I saw them, best $80 I have spent in a long time. Highly recommend.

Pete · Post by **Pete** » Wed Mar 25, 09 7:57 pm

interesting stuff. Is the taper both on crank and cam components - it's hard to tell from the pictures.

I have a balancer remover as well, but I find the installer the best bit of kit

mopar_mark · Post by **mopar_mark** » Wed Mar 25, 09 8:02 pm

Pete wrote:interesting stuff. Is the taper both on crank and cam components - it's hard to tell from the pictures

Pete, taper is only on the top/camshaft pulley, the bottom pulley is parallel

Pete wrote:I find the installer the best bit of kit

Yes, I agree with you there, especially when having to fit the bottom pulley on the jesel, that was a right pain before.

Anonymous · Post by **Anonymous** » Wed Mar 25, 09 10:59 pm

Forgot about this thread.

Anyhows , thanks for the forwarning regards the B1 heads Dunc , if all the B1s are machined in the same mannor then i can see where the potential oiling problems lie....................... all sorted.

Anonymous · Post by **Anonymous** » Wed Mar 25, 09 11:19 pm

mopar_mark wrote:
Yes, I agree with you there, especially when having to fit the bottom pulley on the jesel, that was a right pain before.

10lb of nitrous over the snout does the trick too.

You got a new puller Mark?

Cannonball · Post by **Cannonball** » Wed Mar 25, 09 11:51 pm

mopar_mark wrote:As there were a few questions on a Jesel, thought I would post a couple of pictures, as I just fitted new Top & Bottom seals

Jesel - Without Pulleys & belt - shows the camshaft pulley taper which determines belt tension & centres

Jesel - With Pulleys & belt fitted

Have used a home made Harmonic balancer remover for years, got the job done, but was always a bit of a struggle.

Anyway, to cut a long story short, I bought one for $80. Boy if I had known how good they are. I would of bought one as soon as I saw them, best $80 I have spent in a long time. Highly recommend.

you got enough ponjo round that cover mark,

mopar_mark · Post by **mopar_mark** » Thu Mar 26, 09 12:02 am

I knew someone was going to comment

Yeah, plenty on there, meant to wipe the excess of with me finger, but got side tracked & forgot to do it

Left it to late & it had already started to set.

Could of trimmed it with a knife, but then can get iffy messing around, so let it be

Might look a bit ugly, but at least I know it wont be leaking from there

Was only a small oil leak, but the mess was bleedin unbeleiveable. Oil was getting onto the blower belt, trapped between the belt & pulley & emulsifying & slinging sh te everywhere. Took about 6 hours to get it all clean again

mopar_mark · Post by **mopar_mark** » Thu Mar 26, 09 12:05 am

Brutus wrote:You got a new puller Mark?

Yeah, mate. Your more than welcome to borrow it, when you need it. It's like Chalk & Cheese, can't understand why I never got one sooner.

That old adage about the right tools for the job, couldn't be more truer in this case.

Mind you, if I knew I was gonna get a surprise bonus this week, I would of sent it back to Canada & said fix that
