904 woes

terryr · Post by **terryr** » Sun Aug 12, 12 4:45 pm

having a bit of trouble with the push button in the valiant ,all oil looks good and levels seem ok ,all works fine except its taking along time to drop into top and you have to drop the revs for it to engage ,but once in its not slipping and drives as normal,wondering if it maybe band adjustment ,and if it is ,is it the one inside or outside the box

DaveBishop · Post by **DaveBishop** » Sun Aug 12, 12 5:14 pm

Hi Terry its the one outside the box the intermediate band
Cheers Dave

terryr · Post by **terryr** » Sun Aug 12, 12 5:28 pm

hi dave ,do you rekon its the band causing the delay then

Cannonball · Post by **Cannonball** » Sun Aug 12, 12 5:51 pm

i think you will find your high gear clutch is goosed, try the band in case the timing is out, also be sure your linkage down from the carb is on and set correctly,,,,,,

terryr · Post by **terryr** » Sun Aug 12, 12 5:57 pm

cheers dunc ,ill climb under it in the week ,would it be worth running around the block with the kickdown disconected to see if it changes anything

Dave-R · Post by **Dave-R** » Sun Aug 12, 12 8:24 pm

terryr wrote:cheers dunc ,ill climb under it in the week ,would it be worth running around the block with the kickdown disconected to see if it changes anything

I wouldn't. It would only make things worse. Just check it is adjusted correctly. Also tighten the band until the adjuster is just snug and back off 2 1/4 turns.

DaveBishop · Post by **DaveBishop** » Sun Aug 12, 12 8:29 pm

Ad Duncan says even though the fluid looks OK it seams like there is to much movement in the top and reverse clutches. It a week point on the 904 the intermediate band and the clutches. The kick down linage control's the pressure in the box so if that not adjusted properly you will have problems
